Nano Materials × Panel-Level Packaging: Lighting Up the Future of Touch in 2025

Key Nanomaterials Powering Innovations in Touch Panels at 2025

The 2025 Touch Panel exhibition has just concluded, with major players focusing on e-paper, panel-level packaging (PLP), and innovative applications in display technologies such as foldable large-sized MiniLED and recyclable materials. These trends highlight a shared vision of a more convenient and sustainable future enabled by technology.

As touch panel technologies rapidly evolve, achieving a balance between thinness, high performance, and multifunctional integration has become a critical challenge for system design and manufacturing. Advanced packaging technologies—especially Fan-Out Panel Level Packaging (FOPLP)—enable high density, low thermal resistance, and excellent electrical performance, opening up new opportunities for the touch display sector. At the 2025 exhibition, the integration of FOPLP with key nanomaterials was a major point of interest.

This article introduces three key nanomaterials—Nano-Aluminum Oxide (Nano-Al₂O₃), Nano-Silicon Dioxide (Nano-SiO₂), and Hollow Nano-SiO₂—and explores their roles in the FOPLP architecture, along with how they enhance overall performance and reliability in touch panels.

1. Nano-Aluminum Oxide (Nano-Al₂O₃)

• Enhanced Thermal Conductivity: With excellent thermal conductivity, Nano-Al₂O₃ can be incorporated into packaging materials such as underfill or molding compounds to improve heat dissipation, aiding in thermal management for touch ICs or OLED driver chips.
• Mechanical Reinforcement: Nano-Al₂O₃ particles increase the modulus and crack resistance of packaging materials, reducing warpage caused by thermal stress—particularly crucial for large-format touch modules.
• High Surface Reactivity: After surface treatment, these particles form stable and uniform composites with epoxy resins, improving material consistency.

2. Nano-Silicon Dioxide (Nano-SiO₂)

• Outstanding Insulation: With high resistivity and a low dielectric constant, Nano-SiO₂ is ideal for use in dielectric and buffer layers within FOPLP, enhancing signal integrity and noise immunity.
• Uniform Particle Size: Typically within the 20–100 nm range, the size distribution allows for precise rheological control in coating applications, promoting process stability and fine line design.
• Improved Packaging Integration: Enhances the compatibility and bonding between packaging materials and different panel layers, improving overall module reliability.

3. Hollow Nano-SiO₂

• Low Dielectric Constant: Its hollow structure reduces the k-value even further, supporting high-frequency applications such as 5G communication modules and high-speed touch panel integration.
• Lightweight and Warpage Control: The low density makes it an ideal filler for large or flexible touch display modules, mitigating warpage and reducing weight.
• Optical Extension: Excellent light-scattering and refractive properties make it suitable for optical layers such as light diffusion films and anti-reflective coatings, enhancing brightness uniformity and viewing angles.

Conclusion:
As FOPLP becomes increasingly integrated with high-performance touch panel technologies, nanomaterials like Nano-Al₂O₃, Nano-SiO₂, and Hollow Nano-SiO₂ offer not only intrinsic material benefits but also flexible design and manufacturing possibilities. Through the synergy of materials engineering and advanced packaging structures, these nanomaterials are poised to inject high efficiency, lightweight, and intelligence into the next generation of displays—emerging as standout technologies from the 2025 Touch Panel show.
