Fluorinated acrylic materials: a key formulation for creating next-generation semiconductor and electronic materials

Why Is Fluorinated Acrylic Becoming an Important Choice for Semiconductor Materials?

With the rapid development of advanced packaging, high-frequency and high-speed signal transmission, automotive electronics, and display technologies, semiconductor materials are increasingly required to deliver not only good mechanical strength and processability, but also low dielectric properties, high chemical resistance, low moisture absorption, and high reliability. Although conventional acrylic resins offer excellent transparency, adhesion, and film-forming properties, they are gradually becoming less capable of meeting the requirements of advanced processes in areas such as chemical resistance, water absorption, surface properties, and transparency at lithography wavelengths. As a result, fluorinated acrylics are becoming an increasingly important direction in formulation design.

By introducing high-bond-energy C–F bonds and low-polarity fluorinated functional groups, fluorinated monomers can effectively modify the surface energy, dielectric properties, and weather resistance of the material, making the resulting resins suitable for high-end electronic materials such as photoresist protective layers, wafer protective coatings, advanced packaging dielectric materials, and functional optical films.

Design Applications and Key Features of Fluorinated Acrylic Resins

In formulation design, fluorinated acrylics generally do not completely replace conventional acrylics. Instead, functional monomers such as TFEMA and fluoroalkyl methacrylates are copolymerized with MMA, HEMA, GMA, and other monomers. By adjusting the fluorine content appropriately, an optimal balance between material performance and processability can be achieved.

The key advantages of fluorinated acrylics include:

1. Low surface energy: Enhances hydrophobicity, oleophobicity, and stain resistance while reducing particle adhesion. This makes fluorinated acrylics suitable for immersion lithography and nanoimprint lithography (NIL), where high hydrophobicity and excellent release properties are required to minimize water residue and prevent mold damage.
2. Low polarizability: Helps reduce the dielectric constant, making fluorinated acrylics suitable for high-speed signal transmission and advanced packaging materials. In photoimageable dielectric (PID) materials and redistribution layers (RDL), they can help reduce RC delay and signal crosstalk.
3. Low moisture absorption: Reduces dimensional changes and electrical drift, thereby improving long-term reliability.
4. Strong C–F bonds: Provide excellent chemical resistance, thermal stability, and UV resistance, enabling the material to withstand demanding process conditions such as photoresist development, cleaning, and packaging processes.

It is worth noting that a higher fluorinated monomer content does not necessarily result in better overall performance. Excessive fluorine content may lead to reduced adhesion, poorer compatibility with other resins, and increased material costs. Therefore, the key to developing fluorinated acrylic resins lies in achieving a balance among low dielectric properties, high reliability, and good processability through copolymer design, functional group selection, and crosslinking structure optimization. This balance will remain an important development direction for high-performance semiconductor and electronic materials.

In addition to the fluorinated acrylic monomers described above, we also provide a variety of high-purity acrylic monomer raw materials with low metal content, which can be used for the development of high-end photoresists and polymer synthesis. If you are interested in our products, please feel free to contact us for further discussion.
